MCTLD Series High Current DIP Type Inductor
Ultra low cost.
Shielded construction.
High frequency range up to 1.0 MHz.
Very low DC resistance.
Customized.
All lead-free. (RoHS).
Applications
Motherboards for laptop and desktop computers.
DC/DC converter in distributed power systems or
Inductor for general purpose use.
Mechanical dimension: Unit: mm
Electrical Characteristics:
|
MCT PN |
L(0A) uH±20% |
DCR（mΩ） max |
L（rms） uH±20% |
Irms A |
Isat A |
E |
F |
|
MCTLDR47M |
0.47 |
3.5 |
0.42 |
21 |
35 |
5.5±1 |
0.90 |
|
MCTLDR60M |
0.60 |
3.5 |
0.54 |
20 |
30 |
5.5±1 |
0.90 |
|
MCTLDR80M |
0.80 |
4.0 |
0.70 |
18 |
24 |
6.5±1 |
0.80 |
|
MCTLD1R0M |
1.00 |
6.0 |
0.90 |
16 |
22 |
6.5±1 |
0.70 |
Note:
L0 test condition:100KHz/1.0Vrms，0ADC
Inductance at IDC is a typical value for the component taken at IDC
Heating current will cause an approximate ΔT of 40°C without core loss
Saturation current that will cause L0 approximate 20% rolloff with 25°C ambient temperature
Testing ambient temperature is referenced to 25°C
Operating temperature range -40°C~+120°C
