MCTLC Series High Current DIP Type Inductor

Features
Ultra low cost.
Shielded construction.
High frequency range up to 1.0 MHz.
Very low DC resistance.
Customized.
All lead-free. (RoHS).
Applications
Motherboards for laptop and desktop computers.
DC/DC converter in distributed power systems or
Inductor for general purpose use.
Mechanical dimension: Unit: mm

Electrical Characteristics:

MCT PN	L(0A) uH±20%	DCR（mΩ） max	L（rms） uH±20%	Irms A	Isat A	E	F
MCTLCR47M	0.47	0.90	0.41	34	50	8.7±1	1.5±0.1
MCTLCR60M	0.60	0.90	0.56	33	50	8.7±1	1.5±0.1
MCTLCR80M	0.80	1.50	0.73	32	45	8.4±1	1.3±0.1
MCTLC1R0M	1.00	1.50	0.92	30	45	8.4±1	1.3±0.1

Note:
L0 test condition:100KHz/1.0Vrms，0ADC
Inductance at IDC is a typical value for the component taken at IDC
Heating current will cause an approximate ΔT of 40°C without core loss
Saturation current that will cause L0 approximate 20% rolloff with 25°C ambient temperature
Testing ambient temperature is referenced to 25°C
Operating temperature range -40°C~+120°C
