Features
Ultra low cost.
Shielded construction.
High frequency range up to 1.0 MHz.
Very low DC resistance.
Customized.
All lead-free. (RoHS).
Applications
Motherboards for laptop and desktop computers.
DC/DC converter in distributed power systems or
Inductor for general purpose use.
Mechanical dimension: Unit: mm
Electrical Characteristics:
|
MCT PN |
L(0A) uH±20% |
DCR（mΩ） max |
L（rms） uH±20% |
Irms A |
Isat A |
E |
F |
|
MCTLBR47M |
0.47 |
0.85 (Typ 0.75) |
0.45 |
40 |
54 |
10.0±1 |
1.7±0.1 |
|
MCTLBR60M |
0.60 |
0.85 (Typ 0.75) |
0.55 |
40 |
50 |
10.0±1 |
1.7±0.1 |
|
MCTLBR80M |
0.80 |
0.85 (Typ 0.75) |
0.68 |
36 |
40 |
10.0±1 |
1.7±0.1 |
|
MCTLB1R0M |
1.00 |
1.30 (Typ 1.15) |
0.94 |
34 |
38 |
10.2±1 |
1.5±0.1 |
Note:
L0 test condition:100KHz/1.0Vrms，0ADC
Inductance at IDC is a typical value for the component taken at IDC
Heating current will cause an approximate ΔT of 40°C without core loss
Saturation current that will cause L0 approximate 20% rolloff with 25°C ambient temperature
Testing ambient temperature is referenced to 25°C
Operating temperature range -40°C~+120°C
